The pressing technology for truck body panel

Our truck body panel is fully enclosed composite sandwich structure, the inside and outside surface are the FRP sheet, the thermal insulation layer is rigid polyurethane foam, it is necessary to put into embedded parts, which bonded by glass fiber mat and resin adhesive after hot pressing.The panel structure should be molded without steel structure and cold bridge,the heat preservation performance is good, and with good waterproof performance at the same time, the panel should be high intensity, light weight,it can effectively solve the puzzles of bubble, wrinkles and other technical problems.we require high production efficiency and the production of cars inside and outside surface does not need to spray paint processing.And the surface flatness error should be controlled at 0.5 mm/m or less.

The bottom structure of refrigerated truck body

The bottom of refrigerated truck body adopts integral cast-in-place FRP, it owns good heat preservation performance, high strength, the ventilation slots design facilitate air circulation of whole vehicle, and a balanced load temperature was kept there.Due to the steel frame structure embedded parts in floor wall, the structure is pretty stable. The production of bottom panel is completed, the surface of the bottom plate is adhesive resin + glass fiber to meet the requirements of food grade glass reinforced plastics (FRP), it guarantee the good preservation performance and impact strength of bottom panel.

The application scope of PU composite panel

As building energy-saving insulation materials,Polyurethane composite panels has been widely used in Europe, America, Japan and other developed countries , the penetration rate reaches 80%, but less than 10% is applied in our country.Polyurethane sandwich board as a kind of excellent energy-saving insulation materials, its excellent heat insulation, fire prevention, heat preservation performance can provide efficient solutions to solve the crisis of China's energy consumption .Polyurethane sandwich panel is widely used in large industrial plants, cold storage, garage, mobile houses, pavilion, gymnasium, shopping centers, airports, power plants, villas, hospitals, formation and high-rise office buildings and other fields, because of the excellent heat preservation performance, it is mainly used in industrial and civil roof and wall construction.

The good performance of resin for FRP sheet

Good quality FRP sheet need high quality resin.The resin our used can resist the corrosion.It is resistant to acid of middle density, alkali, various salts environment, and the usage temperature is -50℃～90℃,the highest temperature is 105. The velocity of inflaming retarding is Grade One of ASTM E-84 ,and the flame spreading index is below 25. Another kind of ORP resin type can resist to seawater, weak acid and atmospheric aging environment, the usage temperature is -50℃～60℃, and the highest temperature is 100℃. This is the economical type. Compared with the traditional steel grating, aluminum grating and wood grating, its corrosion resistance is better though its corrosion resistance is weak in all of the resin types. The velocity of inflaming retarding is Grade One of ASTM E-84, and the flame spreading index is below 25.With this kind resin, our FRP sheet can be applied to many kinds of panel or other building purpose.

The development of the commercial refrigerated equippment market

The commercial refrigerated equippment market will reach to 46.6billion dollars by 2018.The annual rising rate is 8.2%. Many factors accelerate the development of the commercial refrigerated equippment market.For example: the development of technology, the change of food consuming model, the expansion of supermarket and fast food business chain, the innovation of plant model, the worldwide export of seafood and processed food.

The importance of highway refrigeration transportation

The highway transportation monopolize southern cold chain transportation market.Many high value-added fruit and vegetable are transported in highway.The highway refrigeration transportation of perish food account for 75%.And short distance transportation almost are highway transportation. It is forecasted that highway refrigerated truck body will be required in many area. The first is the food area ,which including the aquatic product, perish food, frozen food and fruit.The second is medical and health area.To guarantee the safety of medicine, the refrigerated truck body is necessary. The third is the eletronic field, the development of eletronic industry requires more and more refrigerated truck body.

The structure of refrigerated truck body

Refrigerated truck body is mainly used for transportation of all closed environment for meats, vegetables, iced or cold beverages, or even hazardous chemicals. Our refrigerated truck provides you with maneuvering, flexible, efficient, massive, spacious, safe as well as reliable transportation. GRP Plates Thickness of panel is 60-120 mm Stainless steel 304 quality hinges and door locks Panel production with using press technologies Inside protection bars and hygienic accessories PVC mudguard Brick Plywood on floor Requested dimensioning

FRP XPS Composite Panel

XPS composite panel is the abbrievation extruded polystyrene composite panel.XPS is a kind of insulation material.Two side FRP panel and the extruded polystyrene panel core form the FRP XPS composite panel.This kind of composite panel is a great thermal insulation.It owns high gloss finish and long term durability.It can resist damage and easy to be repaired.It can be assembled quickly.The color of XPS is opptional.FRP XPS composite panel has been popularly applied in refrigerated and insulated truck bodies and semi-trailer vans, movable and stationary portable offices and housing, oilfield special truck bodies, special communication and power truck bodies, RV vehicles, caravans and military cabinets, etc.

The comparison between FRP sandwich panel and metal sandwich panel.

The FRP sandwich panel is fabricated by FRP Sheet and Pu rigid foam,its internal and external coverings are integral FRP sheet. While the metal sandwich panel is fabricated by metal skin and XPS or injected PU, its internal and external coverings are individual metal skin.The structure of former one is all closed vacuumized homogeneous construction and without any metallic support frame inside.But the metal one is opened structure and non vacuuming processing, metallic support is put into the frame. The weight of the FRP one is 30% to 70% lighter than metal one.The FRP sandwich panel have excellent insulation.It is more reliable, effective and cost-saving.

The comparison between FRP sandwich panel and metal sandwich panel.

The FRP sandwich panel is fabricated by FRP Sheet and Pu rigid foam,its internal and external coverings are integral FRP sheet. While the metal sandwich panel is fabricated by metal skin and XPS or injected PU, its internal and external coverings are individual metal skin.The structure of former one is all closed vacuumized homogeneous construction and without any metallic support frame inside.But the metal one is opened structure and non vacuuming processing, metallic support is put into the frame. The weight of the FRP one is 30% to 70% lighter than metal one.The FRP sandwich panel have excellent insulation.It is more reliable, effective and cost-saving.

FRP PP honeycomb composite panel

C-SCO FRP PP pp honeycomb sandwich panel own stable constructure. The hole size of honeycomb is 8mm.Each hole is arranged orderly.The shore hardness of it is more than 4.5. Its shore hardness id more than 200mpa, and bending strength more than 12 mpa.It is light comparatively. The weight of 20mm is 7.8kg/㎡,25mm is 8.3kg/㎡,30mm is 8.8kg/㎡.And our maximal size of our panel can reach to 17*3.5m.We can offer any customized size and service. It owns light weight and high indensity,with good fire resistant and insulation performance.It can resist impact,scratch and corrosion.Our FRP PP honeycomb sandwich panel has been widely applied in lots of area: billboard and boat building, indoor partition, product show case and advertising identification panel and so on.

The comparison between FRP sandwich panel and metal sandwich panel.

The FRP sandwich panel is fabricated by FRP Sheet and Pu rigid foam,its internal and external coverings are integral FRP sheet. While the metal sandwich panel is fabricated by metal skin and XPS or injected PU, its internal and external coverings are individual metal skin.The structure of former one is all closed vacuumized homogeneous construction and without any metallic support frame inside.But the metal one is opened structure and non vacuuming processing, metallic support is put into the frame. The weight of the FRP one is 30% to 70% lighter than metal one.The FRP sandwich panel have excellent insulation.It is more reliable, effective and cost-saving.

The prospect of cold chain transportation

The market scale and demand are under the rapid developing situation.The demand of food can reach one hunderd million tons one year. The annual growth rate surpass 8%. Nowadays, 90% of meat, 80% of aquatic product and almost whole fruit and vegetable are transported under the common temperature. Just 5% of vegetable and 15% of meat and 23% of aquatic product have joined the cold chain transportation .The rate of wasting get to 25% to 30%. The cold chain trasportation is the importatnt method to protect the resources.It is tightly contacted to the health and safety of human body.

The branches of cold chain logistics

The concept of “ cold chain” is firstly applied to food industry. But it is widely connected to other industries.

1.cold chain for food: it is a special supply chain system for keeping food under low temperature, so that the food can still be fresh after the process of producing, transporting,distributing and retailing.

2.Cold chain for health care: it refers to the low temperature control to the medicine, vaccine, diagnostic reagent and relevant raw material in the consistent process of raw material purchasing, sample collection, producing, reaserch and development, clinical test, storing and transporting.

3. Cold chain for aviation: it is a professional cold chain logistic system in aerial.

The application of FRP sandwich panel

FRP sandwich panel is a kind of new building material, it owns a lot of advantages and has been applied widely in many area. It can resist the high impact and pressure.Smooth surface, various color for your reference make the panel good-looking. Where does the FRP sandwich panel applied to: 1.Floor,Wall Panel,Coapboard of Bullet Train  2.Billboard,Protective Railing,etc. 3.Floor of Stadium Spectators Stand 4.Floor of Exhibition Stand and Stage 5.Construction Scaffold and Aerial Work Platform 6.Truck Box Board 7.Supermarket  Shelf 8.Deck of Yacht:Deck,Wall Panel,and Roof Panel of interior Cabin 9.Cabin Floor of Airplane 10.Caravan

The branches of cold chain logistics

The concept of “ cold chain” is firstly applied to food industry. But it is widely connected to other industries. 1.cold chain for food: it is a special supply chain system for keeping food under low temperature, so that the food can still be fresh after the process of producing, transporting,distributing and retailing. 2.Cold chain for health care: it refers to the low temperature control to the medicine, vaccine, diagnostic reagent and relevant raw material in the consistent process of raw material purchasing, sample collection, producing, reaserch and development, clinical test, storing and transporting. 3. Cold chain for aviation: it is a professional cold chain logistic system in aerial. welcome to :

The features of cold-chain?

Due to the tight connection to the quality of food, the cold chain is more complicted and supervised more strictly:

1.It is a huge systematic programme for more building invest than normal logistics system.

2.High organization is required for the pragmaticality of perishable food.

3.The operating cost is closely related to the energy cost, so to control the operating cost is important to the cols-chain.

welcome to: www.sandwichpanelfactory.com

What is cold-chain?

The cold chain logistics is a systematic programme, which keeps the perishable food under low and safe temperature in the process of producing, transporting and selling before being consumed. It aims to guarantee the quality of food and reduce the waste.With the development of logistics refrigeration technology, the cold chain logistics bulit on the basis of cryogenic craft, regarding the refrigeration technology as methods.

The cold chain is composed of refrigeration processing, refrigeration storing, refrigeration transporting, refrigeration delivering and refrigeration saling.

welcome to: www.sandwichpanelfactory.com

Professional manufacture of composite panel and truck body

FRP sheet

CSCO composite panel can be used to build the interior and exterior surface of the wall. The fiber reinforced composite panel strengthens the effect of heat resistant.And benefited from the sandwich structure with insulated foam.The insulated property of the fiber reinforced composite panel with thickness of about 60mm can be compared to the wooden panel, whose thickness is 400mm.

What are the features of agricultural products cold-chain logistics?

The transportation of agricultural products is complicated, dynamic, intersectional, accrued and customized. Its features are as following:
1.the chain of agricultural is wide and short.The participant is large, and the market extend to a wide range.So, different kind of transportation chains are formed.The fresh agricultural products have a high demand for time.the short chain is suitable for agricultural products.
2. The transportation of agricultural products need more invest.And the capital is put in to professional area.Unstable market and complicated requirements make the manage and operation be difficult.
3.It requires high information technology.Quick transportation and lower cost in transportation are needed.In the process of transportation, safe quality control and track are necessary, due to the asymmetric information.
4.To avoid the agricultural going bad,the higher coordination of organization among every parts.Actually, the benefits of farmer and person should be safeguard. The problems of wasting and unbalanced market force should be solved.
